UR70 High Efficiency High Frequency Transformer Coil Stable Reliable Performance

Certification : ISO9001:2015, IATF16949:2016, U/L, ROHS, CQC, CE, cUL

Warranty : 5 years

Model Number : UR70

Output Power : 500VA - 5KVA

Price : ＄5.5-7.9/pieces,1000-10000pcs

Solution : One-stop solution

Supply Ability : 5000pcs

Product name : High Power High Frequency Transformer UR70

MOQ : 500pcs

Delivery Time : 7-14 work days (Negotiable)

OEM/ODM : acceptable

Payment Terms : T/T

Supply type : OEM / ODM

Brand Name : Chipsen

Packaging Details : Blister tray or EPE foam packaging + export cartons; bulk orders securely palletized for safe transport. Custom packaging available upon request.

Place of Origin : China

Frequency : 20KHz - 200KHz

Contact Now

UR70 High Efficiency High Frequency Transformer Coil Stable Reliable Performance
Product Overview

The UR70 series stands as our flagship heavy duty magnetic solution engineered for the most demanding high power applications. This robust high frequency transformer utilizes a specialized UR type core geometry to achieve exceptional power throughput while maintaining superior thermal stability. Engineered with premium manganese zinc ferrite and precision multi strand copper windings, the UR70 is designed to be the reliable heart of large scale solar inverters, industrial welding power supplies, and EV charging infrastructures. Our commitment to zero defect manufacturing ensures that each UR70 unit provides the rock solid performance your mission critical power systems require.

Technical Specifications
Category Professional Technical Details
Model Introduction Heavy duty UR70 series high power high frequency transformer
Core Materials High flux Mn-Zn Ferrite core ensures low loss and high efficiency
Winding Technology Precision multi strand oxygen free copper wire for high current load
Safety Compliance Official UL E332338 recognized insulation with full ROHS compliance
Quality Systems Certified IATF 16949 2016 and ISO 9001 2015 production consistency
Power Capability Supports efficient energy conversion for systems from 500W to 5000W
Custom Services Full OEM and ODM support with free engineering design assistance
Outstanding Technical Features
  • High grade ferrite core architecture ensures superior magnetic efficiency and low heat
  • Precision multi strand copper winding significantly reduces skin effect and AC losses
  • Robust metal chassis mounting design provides exceptional mechanical strength and safety
  • Advanced insulation system guarantees high voltage isolation between primary and secondary
  • Integrated open frame structure facilitates superior natural convection heat dissipation
  • Sophisticated automated manufacturing guarantees highly consistent electrical parameters
  • Environmental moisture resistant coating enhances long term reliability in harsh industrial fields
Strategic Advantages and Applications
  • Perfectly optimized for industrial solar grid tie inverters and high power DC DC units
  • The definitive choice for electric vehicle fast charging and automotive power modules
  • Extensively used in industrial robotics, medical imaging systems, and telecommunications
  • Certified quality standards simplify your final product international market entry process
  • Strict 100 percent technical verification ensures reliability before every final shipping
  • More than 20 years expertise ensures industry leading magnetic component reliability
  • Direct factory supply offers highly competitive pricing for global strategic procurement
Frequently Asked Questions
Q1: How long the sample can be ready?
A1: 3-5 days for new samples, 1 day for sample in stock.
Q2: Shipping for samples
A2: When customers cover freight costs, we can help you choose the cheapest shipping way.
Q3: Can you provide technical support for customized products?
A3: Yes, we have strong R&D team who can provide free technical support according to your specific demands. We support customizations in terms of input & output voltage, power, inductance, dimensions, cores material, wire materials, and more.
Q4: Can you accept flexible MOQ?
A4: We support flexible MOQ based on your industry and the characteristics of the products you need. Could you please tell us the application areas of the products you need and the estimated annual usage volume?
Q5: If I have a large quantity of goods that need to be shipped by sea, can you ensure proper packaging and protection for them?
A5: Yes, we can provide the goods packed in strong export carton, on wooden pallet and shrinkwrapped.
