Low Height High Frequency EPC13 SMD Transformer For Telecom and Data Center

Name: Low Height High Frequency EPC13 SMD Transformer For Telecom and Data Center
Brand: Chipsen
Price: 0.58 USD

Quality Low Height High Frequency EPC13 SMD Transformer For Telecom and Data Center for sale

Model Number : EPC13 SMD

Operating Frequency : 10kHz to 500kHz

MOQ : 100 pcs

Delivery Time : 15-30 working days

Storage Temperature : -25°C to +85°C

Packaging Details : Tape&Reel

Payment Terms : T/T

Brand Name : Chipsen

Isolation Voltage : 3000V AC

Place of Origin : China

Operating Temperature : -40°C to +125°C

Price : $0.58-$1.08

Insulation Class : Class B (130°C) or Class F (155°C)

Supply Ability : 200K-500K pcs / Month

Certification : UL/ISO9001/ISO14001/RoHS/Reach

Output Power : 1.0W - 15.0W

Contact Now

Product Introduction

The EPC13 High Frequency SMD Transformer from Chipsen is designed for high-density power conversion in space-constrained applications. Featuring a compact footprint and surface-mount technology, it effectively cuts EMI noise in your circuits while maintaining superior efficiency. Engineered with 26 years of magnetic expertise, this transformer ensures stable power delivery for modern electronics.

Product Features

Our EPC13 series offers a balance of low profile and high power density, ideal for automated pick-and-place assembly.

Technical Parameters	Specification Details
Core Type	High-grade Ferrite EPC13
Mounting Style	SMD (Surface Mount Device)
Operating Frequency	10kHz to 500kHz
Output Power	1.0W - 15.0W (Customizable)
Isolation Voltage (Hi-pot)	3000VAC / 5mA / 60s
Operating Temperature	-40°C to +125°C (Includes self-heating)
Storage Temperature	-25°C to +85°C
Insulation Class	Class B (130°C) or Class F (155°C)
DC Resistance (DCR)	Ultra-low DCR for minimal heat loss
Compliance	UL, CE, RoHS, REACH compliant

Product Applications

Smart Home Systems: Compact power modules for IoT sensors and switches.
LED Lighting Drivers: Efficient DC-DC conversion for slim LED fixtures.
Industrial Control: Reliable signal isolation in PLC and automation modules.
Telecommunications: High-density power supplies for networking equipment.
Medical Electronics: Precision power components for portable diagnostic tools.

Why Choose Chipsen?

Product Advantages

Low Leakage Inductance: Enhances circuit efficiency and reduces voltage spikes.
Excellent Thermal Stability: Operates reliably in harsh industrial environments.
Space-Saving Design: EPC13 core optimizes PCB real estate by up to 30%.

Company Advantages

26 Years Expertise: Founded in 2000, we provide consultant-grade technical support.
Self-Owned Factory: 10,000 sqm production base ensuring consistent quality and lead times.
Certified Quality: ISO 9001/14001 factory with UL, CE, and RoHS product certifications.

Frequently Asked Questions

Q1: Do you support custom design for EPC13 transformers?
A: Yes. Customization is our core strength. Our engineers with over 26 years of experience can optimize parameters based on your specific topology.

Q2: What is your minimum order quantity (MOQ)?
A: The standard MOQ is 100 PCS, ensuring scalable production and cost-efficiency for your projects.

Q3: Which payment methods do you accept?
A: We support multiple secure payment options, including T/T (Bank Transfer), PayPal, and Western Union.

Q4: Are your EPC13 transformers UL certified?
A: Yes, our products use UL-certified insulation systems and comply with CE and RoHS standards for global market entry.

Q5: Can I request samples before bulk ordering?
A: Absolutely. We provide samples for technical verification and circuit testing to ensure perfect matching.

Q6: What is the typical lead time for an order?
A: For standard orders, the lead time is usually 3-4 weeks, depending on the customization requirements and order volume.

Q7: How do you ensure product quality?
A: We follow strict ISO 9001 quality management, conducting 100% electrical testing (inductance, turns ratio, Hi-pot) before shipment.

Q8: Do you provide technical support for circuit integration?
A: Yes, our technical team provides free engineering consultation to help you solve EMI or efficiency challenges during design.
