Stable Low Noise EI76 Control Transformer Efficient Durable For Control Panels

  • 1
  • 2
  • 3

Model Number : EI76

Winding Material : Copper wire

Secondary : 24V 27V 32V

MOQ : 100

Delivery Time : 7-14 work days (Negotiable)

Core Type : UI

Enclouse : NEMA 4X 304 SS

Coil : Double winding

Payment Terms : T/T

Insulation Class : F/H

Temperature Rising : ≤80℃

Efficiency : 95%

Price : ＄183.5-399.8/pieces

Primary Voltage : 240V

Mountingtype : Panel Mount

Supply Ability : 10000pcs

Primary : 240V

Insulation : Epoxy

Temperaturerise : 80°C

Place of Origin : China

Voltage : 36V 120V 60V

Varnish : Vacumn varnish

Certification : UL/cUL Class B/F/H, VDE, CQC

Dielectric Strength : 1800V/min

Number Of Qutputs : 3 Groups

Brand Name : CHIPSEN

Input Current : 12A

Configuration : Encapsulated

Operatingtemperaturerange : -20°C to 40°C

Contact Now

Stable Low Noise EI76 Control Transformer
Efficient, durable control transformer designed for control panels and industrial equipment applications.
Product Overview
The EI76 is an open frame low frequency power and control transformer using a laminated EI silicon steel core with integrated mounting bracket and insulated terminal blocks. It can be customized for voltage conversion, electrical isolation, and auxiliary control power in industrial equipment.
All numerical values are typical engineering references rather than guaranteed ratings. Final specifications depend on approved customer requirements.
Industry Applications & Specifications
Industry and Application Common Input Requirements Common Output Requirements Key Parameters Customization Support
Industrial Automation 110V to 480V AC at 50Hz or 60Hz 12V, 24V, 48V, 110V or 120V AC VA rating, regulation, insulation, temperature rise, terminals and mounting Input taps, output voltage, power capacity, brackets, terminals and protection devices
Machine Tool Control 220V, 230V, 380V, 400V, 415V, 440V or 480V AC 24V, 48V, 110V or 120V AC Inrush capability, vibration resistance, dielectric strength and continuous operation Multiple voltage taps, reinforced insulation, terminals and mounting structure
HVAC Equipment 120V, 208V, 220V, 230V, 240V, 277V, 380V, 400V or 480V AC 12V, 24V or 48V AC Continuous load performance, temperature rise, audible noise and installation size Primary voltage, secondary voltage, VA rating, thermal protection and bracket
Medical Equipment Region specific mains voltage Application specified isolated AC output Insulation, leakage current, temperature rise, noise and traceability Shielding, insulation system, protection devices and testing documentation
Commercial Appliances 110V, 120V, 220V, 230V or 240V AC 9V, 12V, 18V, 24V, 36V or 48V AC Efficiency, cost, regulation, compact construction and terminal safety Windings, voltage ratio, terminals, bracket, label and packaging
Customization Parameters
Parameter Typical Reference Customization Status
Core Type EI76 laminated silicon steel core Customizable
Operating Frequency 50Hz, 60Hz or dual frequency design Customizable
Primary Voltage 100V to 480V AC depending on winding and insulation design Customizable
Secondary Voltage 6V to 120V AC commonly requested Customizable
Power Capacity Approximately 30VA to 150VA depending on stack size and temperature rise Customizable
Primary Configuration Single input, dual input or multiple voltage taps Customizable
Secondary Configuration Single, dual or multiple output windings Customizable
Product Construction
Construction Element Description
Magnetic Core EI76 laminated silicon steel core for 50Hz and 60Hz operation
Primary Winding Copper winding designed for single, dual or multiple input voltages
Secondary Winding Single or multiple copper windings developed for required output
Bobbin Insulating coil former selected according to voltage and temperature requirements
Insulation System Barriers, tape, sleeving, margins and interlayer insulation based on approved design
Terminal Blocks Insulated terminals for accessible and reliable equipment wiring
Key Characteristics
  • EI76 laminated silicon steel core
  • Designed for 50Hz and 60Hz power systems
  • Stable voltage conversion and electrical isolation
  • Open frame structure supporting natural heat dissipation
  • Low audible noise design available
  • Single, dual or multiple primary voltage options
  • Single or multiple secondary output options
  • Insulated terminal blocks for convenient wiring
  • Integrated metal bracket for secure installation
  • Custom step down, step up and isolation configurations
  • Optional thermal fuse or temperature protector
  • Optional electrostatic shielding
Applications
  • Industrial automation equipment
  • Machine tool control circuits
  • Control cabinets and electrical panels
  • HVAC control systems
  • Motor control panels
  • Programmable logic controller systems
  • Relay and contactor circuits
  • Medical and laboratory equipment
  • Test and measurement instruments
  • Commercial and professional appliances
Quality Control
Inspection Item Inspection Purpose
Turns Ratio Test Confirms designed primary and secondary voltage relationship
No Load Voltage Test Verifies secondary output without connected load
Full Load Voltage Test Confirms output voltage and regulation at rated load
No Load Current Test Evaluates core excitation and magnetic assembly performance
Winding Resistance Test Confirms winding consistency and conductor condition
Insulation Resistance Test Evaluates insulation between windings, core, bracket and terminals
Why Choose Chipsen
  • Customized primary and secondary voltage combinations
  • Single, dual and multiple winding configurations
  • Drawing based and sample based replacement development
  • Custom power capacity, regulation and temperature rise design
  • Insulated terminal block and wiring customization
  • Integrated bracket and mounting dimension customization
  • Optional thermal fuse, thermostat and electrostatic shield
  • Insulation design based on actual working voltage and environment
  • Low noise and thermal optimization for industrial equipment
  • Prototype development and evaluation support
Frequently Asked Questions
What information is required to customize an EI76 transformer?
Please provide input voltage, frequency, output voltage, output current or VA rating, duty cycle, ambient temperature, maximum dimensions, mounting method, terminal arrangement, insulation requirements, protection requirements, certification needs and annual demand.
What power rating can an EI76 transformer provide?
Approximately 30VA to 150VA is typical. Actual capacity depends on core stack thickness, frequency, voltage regulation, temperature rise, winding construction, enclosure ventilation and operating duty.
Can the transformer support several input voltages?
Yes. Dual primary windings or multiple voltage taps can be designed for different supply voltages. Connection method must be defined in the approved wiring diagram.
Can multiple output voltages be provided?
Yes. Single, dual or multiple secondary windings can be designed when winding space, power capacity, insulation and temperature rise permit.
